Verdict T8M Dial Test Indicator (T8 Metric), 26.5mm Dial, Graduation 0.01mm, Range 0.5mm
Code
T8M
Categories: Default Category, Lever Indicators
| Range | 0.5 mm |
|---|---|
| Display | Analogue |
| Measuring units | Metric |
| Graduation | 0.01mm |
| Dial Face Diameter | 26.5mm |
| Circular Scale Dial | 0-0.25-0 |
| Stylus Length | 19.5mm |
| Standard | Manufacturer's |
| Manufacturer | Verdict |
The Verdict T8 is a slim-profile dial test indicator engineered for restricted-access measurement inside bores, slots and machined cavities where a low-clearance head is essential.
Every Verdict dial test indicator runs on jewelled bearings with a precision worm-spiral movement and uses Verdict's patented pear-shaped stylus, which keeps the contact point the same distance from the pivot as the stylus is tilted, avoiding cosine error. A switch lever reverses the direction of stylus movement for positive or negative inspection.
Features
- Brand: Verdict
- Part number (MPN): T8M
- Type: Dial test indicator (lever type)
- Model: T8 Metric
- Measurement system: Metric
- Dial diameter: 26.5 mm
- Graduation: 0.01 mm
- Dial reading: 0-0.25-0
- Measuring range: 0.5 mm
- Stylus length: 19.5 mm
- Bearings: Jewelled
- Mounting: 4 mm / ¼" top spigot, dovetail body; holder side-clamp accepts rods up to 6.5 mm / 0.256"
- Made in: United Kingdom (Verdict Gauge Limited)
