Verdict T31M Dial Test Indicator (T31 Metric), 35mm Dial, Graduation 0.01mm, Range 1.0mm

The Verdict T31 extends the measuring range of the T30 platform, offering twice the travel for setup and inspection tasks that demand more stylus movement in a familiar 1 3/8"/35 mm package.

Every Verdict dial test indicator runs on jewelled bearings with a precision worm-spiral movement and uses Verdict's patented pear-shaped stylus, which keeps the contact point the same distance from the pivot as the stylus is tilted, avoiding cosine error. A switch lever reverses the direction of stylus movement for positive or negative inspection.

Features

• Brand: Verdict
• Part number (MPN): T31M
• Type: Dial test indicator (lever type)
• Model: T31 Metric
• Measurement system: Metric
• Dial diameter: 35 mm
• Graduation: 0.01 mm
• Dial reading: 0-0.5-0
• Measuring range: 1.0 mm
• Stylus length: 40.59 mm
• Bearings: Jewelled
• Mounting: 4 mm / ¼" top spigot, dovetail body; holder side-clamp accepts rods up to 6.5 mm / 0.256"
• Made in: United Kingdom (Verdict Gauge Limited)

Please note: the images shown are of the Verdict T31I (T31 Imperial) model.
