Verdict T30I Dial Test Indicator (T30 Imperial), 1 3/8" Dial, Graduation 0.0005", Range 0.02"
Code
T30I
Categories: Default Category, Lever Indicators
| Range | 0.020" |
|---|---|
| Display | Analogue |
| Measuring units | Inch |
| Graduation | 0.0005" |
| Dial Face Diameter | 1 3/8in |
| Circular Scale Dial | 0-10-0 |
| Stylus Length | 0.811" |
| Standard | Manufacturer's |
| Manufacturer | Verdict |
The Verdict T30 is a 1 3/8"/35 mm dial test indicator with a longer stylus than the standard T-series, providing improved reach into recessed features without sacrificing dial visibility.
Every Verdict dial test indicator runs on jewelled bearings with a precision worm-spiral movement and uses Verdict's patented pear-shaped stylus, which keeps the contact point the same distance from the pivot as the stylus is tilted, avoiding cosine error. A switch lever reverses the direction of stylus movement for positive or negative inspection.
Features
- Brand: Verdict
- Part number (MPN): T30I
- Type: Dial test indicator (lever type)
- Model: T30 Imperial
- Measurement system: Imperial
- Dial diameter: 1 3/8"
- Graduation: 0.0005"
- Dial reading: 0-10-0
- Measuring range: 0.02"
- Stylus length: 0.811"
- Bearings: Jewelled
- Mounting: 4 mm / ¼" top spigot, dovetail body; holder side-clamp accepts rods up to 6.5 mm / 0.256"
- Made in: United Kingdom (Verdict Gauge Limited)
Please note: the images shown are of the Verdict T30M (T30 Metric) model.
