Verdict T27M Dial Test Indicator (T27 Metric), 50mm Dial, Graduation 0.01mm, Range 0.5mm
Code
T27M
Categories: Default Category, Lever Indicators
| Range | 0.5 mm |
|---|---|
| Display | Analogue |
| Measuring units | Metric |
| Graduation | 0.01mm |
| Dial Face Diameter | 50mm |
| Circular Scale Dial | 0-0.25-0 |
| Stylus Length | 20.29mm |
| Standard | Manufacturer's |
| Manufacturer | Verdict |
The Verdict T27 is a 2"/50 mm dial test indicator with an extended stylus and balanced range, designed for general machine setup, alignment and inspection where larger dial readability is preferred.
Every Verdict dial test indicator runs on jewelled bearings with a precision worm-spiral movement and uses Verdict's patented pear-shaped stylus, which keeps the contact point the same distance from the pivot as the stylus is tilted, avoiding cosine error. A switch lever reverses the direction of stylus movement for positive or negative inspection.
Features
- Brand: Verdict
- Part number (MPN): T27M
- Type: Dial test indicator (lever type)
- Model: T27 Metric
- Measurement system: Metric
- Dial diameter: 50 mm
- Graduation: 0.01 mm
- Dial reading: 0-0.25-0
- Measuring range: 0.5 mm
- Stylus length: 20.29 mm
- Bearings: Jewelled
- Mounting: 4 mm / ¼" top spigot, dovetail body; holder side-clamp accepts rods up to 6.5 mm / 0.256"
- Made in: United Kingdom (Verdict Gauge Limited)
