Verdict T1M Dial Test Indicator (T1 Metric), 25mm Dial, Graduation 0.01mm, Range 0.8mm
Code
T1M
Categories: Default Category, Lever Indicators
| Range | 0.8mm |
|---|---|
| Display | Analogue |
| Measuring units | Metric |
| Graduation | 0.01mm |
| Dial Face Diameter | 25mm |
| Circular Scale Dial | 0-0.4-0 |
| Stylus Length | 13.7mm |
| Standard | Manufacturer's |
| Manufacturer | Verdict |
The Verdict T1 is the compact workhorse of the T-series — a lever-type dial test indicator built for tight-access machine setup and inspection where a small footprint and standard 0.0005"/0.01 mm resolution are required.
Every Verdict dial test indicator runs on jewelled bearings with a precision worm-spiral movement and uses Verdict's patented pear-shaped stylus, which keeps the contact point the same distance from the pivot as the stylus is tilted, avoiding cosine error. A switch lever reverses the direction of stylus movement for positive or negative inspection.
Features
- Brand: Verdict
- Part number (MPN): T1M
- Type: Dial test indicator (lever type)
- Model: T1 Metric
- Measurement system: Metric
- Dial diameter: 25 mm
- Graduation: 0.01 mm
- Dial reading: 0-0.4-0
- Measuring range: 0.8 mm
- Stylus length: 13.7 mm
- Bearings: Jewelled
- Mounting: 4 mm / ¼" top spigot, dovetail body; holder side-clamp accepts rods up to 6.5 mm / 0.256"
- Made in: United Kingdom (Verdict Gauge Limited)
