Mitutoyo 547-320A ABSOLUTE Digimatic Thickness Gauge, Range 0-10mm, Resolution 0.01mm, Throat Depth 120mm
Code
547-320A
Categories: Default Category, Thickness Gauges & Caliper Gauges
| Manufacturer | Mitutoyo |
|---|---|
| Display | Digital |
| Depth of Jaw | 120 mm |
| Range | 0-10mm |
| Resolution | 0.01 mm/0.0005" |
| Measuring Force | 1.5N |
| Measuring units | Inch-Metric |
| Accuracy | 0.02 mm |
| Country of Manufacture | Japan |
The Mitutoyo 547-320A is an ABSOLUTE Digimatic dial-type thickness gauge for fast, accurate thickness measurement of thin products such as paper, film and felt. The bezel and crystal are moulded as one piece to keep out water and oil, and data output connects to SPC and measurement systems.
- Measuring range: 0-10 mm (0-.4")
- Resolution: 0.01 mm (.0005")
- Accuracy: ±20 µm (±.001")
- Measuring force: 1.5 N or less
- Type: Deep throat, ceramic spindle/anvil
- Throat depth: 120 mm
Made in Japan by Mitutoyo.
