Mitutoyo 178-741-13 Surftest SJ-220 Portable Surface Roughness Tester, Standard Drive, Stylus 2µm/60°, 0.75mN
Code
178-741-13
Categories: Default Category, Surface Finish
| Manufacturer | Mitutoyo |
|---|---|
| Measuring units | Inch-Metric |
| Range | 360µm |
| Stylus Type | Diamond 2µm/60° |
| Filter | Gaussian / 2CR / PC75 |
| Cut-off Length | 0.08/0.25/0.8/2.5mm |
| Measuring Speed | 0.25/0.5/0.75/1mm/s |
| Power Supply | Rechargeable Battery |
| Country of Manufacture | Japan |
The Mitutoyo 178-741-13 is a compact portable surface roughness tester with a 2.8-inch backlit touchscreen that fits in one hand. It supports touch, flick and swipe operation, 25 display languages and the new ISO 21920 surface texture standard as well as conventional roughness standards. An optional wireless unit adds Bluetooth communication with a PC or smartphone, and free software creates inspection reports from the measured data.
- Drive unit: standard, measuring range 17.5 mm
- Detector: 178-296, differential inductance, skidded
- Stylus tip: 60° / 2 µm radius, measuring force 0.75 mN
- Detector range: 360 µm (-200 to +160 µm)
- Measuring speed: 0.25, 0.5, 0.75, 1mm/s (returning 1 mm/s)
- Standards: JIS'82, JIS'94, JIS'01, ISO'97, ANSI, VDA, ISO 21920
- Digital filters: Gaussian, 2CR75, PC75
- Cutoff length: λc 0.08, 0.25, 0.8, 2.5 mm
- Outputs: USB, Digimatic, printer, RS-232C, footswitch
- Power: AC adapter or rechargeable battery, approx. 1,000 measurements per charge
- GO/±NG judgement and customisable parameters
- Optional memory card for 500 setups and 10,000 measured profiles
Made in Japan by Mitutoyo.
